Engine Management options for Non-Turbo? (S5 SP)
10-13-10, 10:22 PM
#1
Engine Management options for Non-Turbo? (S5 SP)
I rescently built a S5 NA motor and did a large streetport during the build.
After install and longblock assembly I could get it to idle, but after about 30-60 seconds it wanted to surge and die. After numerous adjustments to the throttle body, TPS, and installing S5 turbo injectors and an FD fuel pump the problem was still. I installed a new TPS and set it to FSM spec and the problem only got worse.
The only way i could get it to run better and idle was to set the tps way out, tricking the computer to think the throttle was out, and giving the engine more fuel in compensation for the much more than stock amount of air the engine is getting. I also might add I have a ported and modified throttle body on the engine now as well as 3" aluminum intake piping, and emmisions delete.
So after all of this. I came to the conclusion that I am in need of either some sort of piggyback system that will deliver more fuel to my Large streetport 6 port engine or a stand alone system.
What are my options?
After install and longblock assembly I could get it to idle, but after about 30-60 seconds it wanted to surge and die. After numerous adjustments to the throttle body, TPS, and installing S5 turbo injectors and an FD fuel pump the problem was still. I installed a new TPS and set it to FSM spec and the problem only got worse.
The only way i could get it to run better and idle was to set the tps way out, tricking the computer to think the throttle was out, and giving the engine more fuel in compensation for the much more than stock amount of air the engine is getting. I also might add I have a ported and modified throttle body on the engine now as well as 3" aluminum intake piping, and emmisions delete.
So after all of this. I came to the conclusion that I am in need of either some sort of piggyback system that will deliver more fuel to my Large streetport 6 port engine or a stand alone system.
What are my options?
10-13-10, 11:16 PM
#3
your giving it to much fuel as it is. n/a dosnt need bigger than stock injectors/fuel pump for your situation. Go back to stock fuel system and get a s-afc to do some slight tuning. OR if you plan to go all out in the future then get a standalone ecu/wideband +whatever else installed and have a pro tune it.
10-14-10, 10:35 AM
#5
Now With 10th AE Fun!
iTrader: (1)
Join Date: Jun 2005
Location: CA
Posts: 1,869
Likes: 0
Received 0 Likes
on
0 Posts
Rtek 2.1 is an option too. www.digitaltuning.com
10-14-10, 11:01 AM
#6
I think Haltech Sprint RE is a bit much for an N/A build considering you get the same (pretty much) performance out of an Rtek 2.X. If you wan't to go full standalone I'd suggest it but an Rtek will give you better tuning options (safer) than a piggyback for WAY less than a stand alone.
Rtek is probably your best bet.
Rtek is probably your best bet.
10-14-10, 11:08 AM
#7
I think Haltech Sprint RE is a bit much for an N/A build considering you get the same (pretty much) performance out of an Rtek 2.X. If you wan't to go full standalone I'd suggest it but an Rtek will give you better tuning options (safer) than a piggyback for WAY less than a stand alone.
Rtek is probably your best bet.
Rtek is probably your best bet.
a stand alone is light years above what a rtec can offer, and the fact that you can use a sprint re with a plug and play harness? null an void on the rtec.
Trending Topics
10-14-10, 12:35 PM
#8
A Haltech platinum sport will offer a bunch of features you don't need for an n/a engine and will cost a large percentage of the vehicles resale value. The Rtek can control fuel (including cranking fuel), timing, aux ports, and VDI basically by making adjustments to the factory computer. It won't require anywhere near the amount of time and money investment.
10-14-10, 01:29 PM
#9
A Haltech platinum sport will offer a bunch of features you don't need for an n/a engine and will cost a large percentage of the vehicles resale value. The Rtek can control fuel (including cranking fuel), timing, aux ports, and VDI basically by making adjustments to the factory computer. It won't require anywhere near the amount of time and money investment.
10-14-10, 07:29 PM
#11
However, some have said too much fuel. Agreed again. FD fuel pump and 550 cc injectors are overkill for an NA. Maybe a BP would require that.
10-15-10, 12:17 AM
#12
your giving it to much fuel as it is. n/a dosnt need bigger than stock injectors/fuel pump for your situation. Go back to stock fuel system and get a s-afc to do some slight tuning. OR if you plan to go all out in the future then get a standalone ecu/wideband +whatever else installed and have a pro tune it.
10-15-10, 12:18 AM
#13
Rtek 2.1 is an option too. www.digitaltuning.com
10-15-10, 12:20 AM
#14
Agreed. We don't need a computer argument. Each have valued "opinions". Anyway agreed on vacuum leak. On a cold motor, you kind of "need" a vac leak. helps the idle run higher with that extra fuel. A BAC valve like I use is a glorified vacuum leak. When cold if the settings are right, you're good. When warmed up they may not be right and the car will die. Surging is an easy way to determine vac leak.
However, some have said too much fuel. Agreed again. FD fuel pump and 550 cc injectors are overkill for an NA. Maybe a BP would require that.
However, some have said too much fuel. Agreed again. FD fuel pump and 550 cc injectors are overkill for an NA. Maybe a BP would require that.
10-15-10, 07:46 PM
#15
A standalone is a great thing but unless you need all the little extra power you can get or plan on turbo in future then i wouldnt bother. A s-afc is fine for you. Rtek is great but meh you just dont need it! Is this a daily driver, track car or both?
10-15-10, 11:57 PM
#16
I dont know. but either way you dont need upgraded injectors,fuel pump or fpr.
A standalone is a great thing but unless you need all the little extra power you can get or plan on turbo in future then i wouldnt bother. A s-afc is fine for you. Rtek is great but meh you just dont need it! Is this a daily driver, track car or both?
A standalone is a great thing but unless you need all the little extra power you can get or plan on turbo in future then i wouldnt bother. A s-afc is fine for you. Rtek is great but meh you just dont need it! Is this a daily driver, track car or both?
How much can I tune with the safc? It looks like I can tune more with the Rtek.
The main things I am wanting to tune are obviously air and fuel. It would be nice to have the 6pi and VDI tuneable as well.
I might also add that this is a very large streetport. Infact It was ported about as far as possible without going overboard.
10-16-10, 09:15 AM
#17
I think Haltech Sprint RE is a bit much for an N/A build considering you get the same (pretty much) performance out of an Rtek 2.X. If you wan't to go full standalone I'd suggest it but an Rtek will give you better tuning options (safer) than a piggyback for WAY less than a stand alone.
Rtek is probably your best bet.
Rtek is probably your best bet.
Talk about nostalgia.
I want my iPhone or macbook for tuning. Preferably my iPhone though.
10-16-10, 10:53 AM
#18
Engine, Not Motor
iTrader: (1)
Join Date: Feb 2001
Location: London, Ontario, Canada
Posts: 29,789
Likes: 0
Received 108 Likes
on
91 Posts
Heh, good luck finding tuning products that work with an iPhone or Macbook.
Almost all tuning software is Windows only, and for good reason.
Now, the Megasquirt has several Java based tuning programs that work on most Unix based platforms. Not sure about the iPhone though, considering it really doesn't have any I/O and is a closed platform.
Really, the tuning solution you look for will depend on want you want to do. The RTek will do the job just fine, but a full standalone will go farther and allow you to upgrade in the future if you suddenly decide that you want to go to forced induction. The disadvantage of a full standalone is that you need to start from scratch: wire it into the car, then tune all the maps yourself.
Almost all tuning software is Windows only, and for good reason.
Now, the Megasquirt has several Java based tuning programs that work on most Unix based platforms. Not sure about the iPhone though, considering it really doesn't have any I/O and is a closed platform.
Really, the tuning solution you look for will depend on want you want to do. The RTek will do the job just fine, but a full standalone will go farther and allow you to upgrade in the future if you suddenly decide that you want to go to forced induction. The disadvantage of a full standalone is that you need to start from scratch: wire it into the car, then tune all the maps yourself.
10-16-10, 08:13 PM
#19
Really, the tuning solution you look for will depend on want you want to do. The RTek will do the job just fine, but a full standalone will go farther and allow you to upgrade in the future if you suddenly decide that you want to go to forced induction. The disadvantage of a full standalone is that you need to start from scratch: wire it into the car, then tune all the maps yourself.
Looks like for now I will be going with the Rtek. Possibly in the futue with the turbo I may choose a stand alone unit.
10-18-10, 02:06 PM
#21
One piece of advice - whatever you get, it's a HUGE help to have local tuning support! Discussing what standalone or piggyback is best means nothing if you don't have anyone that can tune it properly. Yes, you can learn to do it yourself, but an experienced is worth their weight in gold.
I put a microtech on my '86 NA and it's great - although I have moved across the country since I installed it, and now I have no local shops that can tune it for me which is frustrating.
10-18-10, 03:23 PM
#22
I bought my Haltech Sprint RE from Chris Ludwig when he was having that group buy sale on all Haltech stuff.. I picked my Sprint RE brand new with brand new wiring harness for a tad bit more than you'd spend on getting an Rtec 2.X on your existing ECU.
It's limited on outputs on my cosmo engine, but it's okay. On an N/A like yours, it would give you great results!
10-18-10, 09:44 PM
#23
Agreed!
I bought my Haltech Sprint RE from Chris Ludwig when he was having that group buy sale on all Haltech stuff.. I picked my Sprint RE brand new with brand new wiring harness for a tad bit more than you'd spend on getting an Rtec 2.X on your existing ECU. It's limited on outputs on my cosmo engine, but it's okay. On an N/A like yours, it would give you great results!
I bought my Haltech Sprint RE from Chris Ludwig when he was having that group buy sale on all Haltech stuff.. I picked my Sprint RE brand new with brand new wiring harness for a tad bit more than you'd spend on getting an Rtec 2.X on your existing ECU.
It's limited on outputs on my cosmo engine, but it's okay. On an N/A like yours, it would give you great results!o well. guess people like the rtec. and 20 year old harnesses, and 20 year old sensors that cost an arm and a leg.
10-18-10, 10:22 PM
#24
Agreed!
I bought my Haltech Sprint RE from Chris Ludwig when he was having that group buy sale on all Haltech stuff.. I picked my Sprint RE brand new with brand new wiring harness for a tad bit more than you'd spend on getting an Rtec 2.X on your existing ECU. It's limited on outputs on my cosmo engine, but it's okay. On an N/A like yours, it would give you great results!
I bought my Haltech Sprint RE from Chris Ludwig when he was having that group buy sale on all Haltech stuff.. I picked my Sprint RE brand new with brand new wiring harness for a tad bit more than you'd spend on getting an Rtec 2.X on your existing ECU.
It's limited on outputs on my cosmo engine, but it's okay. On an N/A like yours, it would give you great results!
10-18-10, 10:35 PM
#25
It'll definitely tune a turbo motor. I've got a T04S on my 13BRE so I'm definitely one testament that you can tune it with a turbo engine. Only thing is, like I said, it's limited on outputs. A lot more options than Rteks though.. It's got one dedicated thermofan output, one dedicated tacho output, and 2 generic outputs that can be configured. Spend an extra $60 on the boost control solenoid and it will control boost. It doesn't do closed loop boost control but it'll still work. I'll be using my 2 outputs for AI and boost control.
You can also get GM water temp sensors and air temperature sensors with metric threads on them. My water temp sensor screwed right into the stock thermo sensor bung.. and for the air temp sensor, I just dripped/tapped the stock location and it fit right in
It's got one dedicated thermofan output, one dedicated tacho output, and 2 generic outputs that can be configured. Spend an extra $60 on the boost control solenoid and it will control boost. It doesn't do closed loop boost control but it'll still work. I'll be using my 2 outputs for AI and boost control.You can also get GM water temp sensors and air temperature sensors with metric threads on them. My water temp sensor screwed right into the stock thermo sensor bung.. and for the air temp sensor, I just dripped/tapped the stock location and it fit right in
