AN coolant lines for turbo..who's done it?
#1
Auto-Ex Noob
Thread Starter
iTrader: (1)
Join Date: Nov 2003
Location: new hampshire
Posts: 209
Likes: 0
Received 0 Likes
on
0 Posts
I would just like to see pictures of the AN fitting that was used for the side closest to the intake manifold. I have tried a straight...and a 90° but I don't like how close the line runs to the exhuast manifold.
#3
Auto-Ex Noob
Thread Starter
iTrader: (1)
Join Date: Nov 2003
Location: new hampshire
Posts: 209
Likes: 0
Received 0 Likes
on
0 Posts
That's how I ran my feed line. I used a 10 mm yor-loc fitting on the rear iron nipple. And Then 3/8 npt to -6an adapter.
What did you run for the return line? On the inside between the turbo and the intake manifold.
What did you run for the return line? On the inside between the turbo and the intake manifold.
#5
Auto-Ex Noob
Thread Starter
iTrader: (1)
Join Date: Nov 2003
Location: new hampshire
Posts: 209
Likes: 0
Received 0 Likes
on
0 Posts
45° sticks out further then a 90°....that's just math.... ..... it needs to hug turbo more in my opinion. i was hoping some one on here had a picture of one that used a 120° fitting
Trending Topics
#8
1308ccs of awesome
iTrader: (9)
That bolt is an m16x1.5 (at least it is on my turbo, I've seen people claim it's M14)
in that case the only banjo that I know of that's big enough is this one:
Search Results | 776-06-14M
and it's M16 -> -8AN
#9
Auto-Ex Noob
Thread Starter
iTrader: (1)
Join Date: Nov 2003
Location: new hampshire
Posts: 209
Likes: 0
Received 0 Likes
on
0 Posts
Just have to dig deeper and think outside the box.. it's meant for a 5/8 bolt..which is .6237 major diameter and a m16x1.5 has a major diameter of .6286 so a few mins in the mill taking off about .005.. easy day..thanks for the idea.
http://www.jegs.com/webapp/wcs/store...&storeId=10001
http://www.jegs.com/webapp/wcs/store...&storeId=10001
#10
Retired Moderator, RIP
iTrader: (142)
Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,581
Likes: 0
Received 131 Likes
on
114 Posts
actually you do not need a banjo bolt.
You can get a adapter from M14(or M16,whatever the size is) to -6AN and put a 90 degree on it and run your hose.
I just went through this whole mess.I lost a "stock bolt" But I had 2 adapters from another setup.
looks something like this:
http://www.jegs.com/i/Russell/799/67...oductId=756667
You can get a adapter from M14(or M16,whatever the size is) to -6AN and put a 90 degree on it and run your hose.
I just went through this whole mess.I lost a "stock bolt" But I had 2 adapters from another setup.
looks something like this:
http://www.jegs.com/i/Russell/799/67...oductId=756667
Last edited by misterstyx69; 11-18-14 at 01:02 PM.
#12
Retired Moderator, RIP
iTrader: (142)
Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,581
Likes: 0
Received 131 Likes
on
114 Posts
I ran the coolant hose from the waterpump under the turbo to the Strut tower side.I point the 90 degree downwards.
The "rear engine outlet" coolant hose goes over the turbo,Using some rubber clamps that hold onto the block off plates and and routed the hose down to the Turbo CHRA in between the turbo and the waterpump.
Sort of a backwards way of routing things but it makes it simpler and actually pretty neat looking.
*I'm replacing the turbo hopefully in the morning(new one came in) so If I "think of it" I will snap pics.
The "rear engine outlet" coolant hose goes over the turbo,Using some rubber clamps that hold onto the block off plates and and routed the hose down to the Turbo CHRA in between the turbo and the waterpump.
Sort of a backwards way of routing things but it makes it simpler and actually pretty neat looking.
*I'm replacing the turbo hopefully in the morning(new one came in) so If I "think of it" I will snap pics.
Last edited by misterstyx69; 11-18-14 at 10:36 PM.
#16
Retired Moderator, RIP
iTrader: (142)
Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,581
Likes: 0
Received 131 Likes
on
114 Posts
Manny Joe and Jack are all next door..in the USA!
(no Pep Boys in Canada.)
***edit this post as to not clutter things up.
Fitting for 14mm coolant passage
Russell Part #670520
this part has 14mm threads to go into the CHRA and a -6 A/N Male fitting,so you can(if you wish) put a 90 degree on that area for the Turbo coolant hose.
I found this actually cheap to do.
The Banjo bolt itself is about 14 bucks,and then the Hose end Barb is another 10-15 bucks.
The Russell part is 5 bucks USD.So I got 2 shipped and received today and will put them on.
(no Pep Boys in Canada.)
***edit this post as to not clutter things up.
Fitting for 14mm coolant passage
Russell Part #670520
this part has 14mm threads to go into the CHRA and a -6 A/N Male fitting,so you can(if you wish) put a 90 degree on that area for the Turbo coolant hose.
I found this actually cheap to do.
The Banjo bolt itself is about 14 bucks,and then the Hose end Barb is another 10-15 bucks.
The Russell part is 5 bucks USD.So I got 2 shipped and received today and will put them on.
Last edited by misterstyx69; 11-21-14 at 10:38 PM.
