What Size Is The Flywheel Nut?

Reply




Old 10-19-04, 09:09 AM
  #1
Full Member
5 Year Member
Thread Starter

Join Date: Jan 2004
Location: north carolina
Posts: 129
Thanks: 0
Thanked 0 Times in 0 Posts
What Size Is The Flywheel Nut?

I Need To Get A Socket Today And Am Not Sure What Size It Is.
werd is offline
Reply With Quote
Old 10-19-04, 09:12 AM
  #2
love the braaaap

85rotarypower's Avatar

Join Date: Jul 2003
Location: Bognor, Ontario
Posts: 3,771
Thanks: 0
Thanked 3 Times in 3 Posts
54mm or 2 1/8" I know because I just removed a flywheel from an engine.

Last edited by vipernicus42; 09-09-05 at 01:54 PM.
85rotarypower is offline
Reply With Quote
Old 10-19-04, 09:22 AM
  #3
Full Member
5 Year Member
Thread Starter

Join Date: Jan 2004
Location: north carolina
Posts: 129
Thanks: 0
Thanked 0 Times in 0 Posts
Thanks / Did You Have Any Trouble Getting The Flywheel Off?
werd is offline
Reply With Quote
Old 10-19-04, 09:34 AM
  #4
Junior Member
iTrader: (1)

kennetht638's Avatar

Join Date: Jun 2004
Location: CA
Posts: 17
Thanks: 0
Thanked 0 Times in 0 Posts
My flywheel was surprisingly easy to remove considering all the horror stories I had read on the forums. All I had to do was thread the nut back on a little (so the flywheel doesn't fall off and hurt something) and beat the flywheel with a rubber mallet until it vibrated itself off. The nut was easy too once I borrowed a socket and impact gun from work.
kennetht638 is offline
Reply With Quote
Old 10-19-04, 09:37 AM
  #5
Senior Member
iTrader: (2)

Join Date: Feb 2003
Location: Kingston Ontario
Posts: 715
Thanks: 0
Thanked 0 Times in 0 Posts
Flywheel fun

Boy your going to have fun if you dont have air tools, or something that will lock the engine TIGHT. We used a piece of 9 foot long angled bedframe and bolted it to the flywheel and then kept adding on to our breaker bar. However like all nuts try bouncing in either direction for a second to attempt to crack her. I suggest if you can using air tool;they works like a charm. If you dont have a flywheel puller you can just bolt an old 1/2" thick piece of metal and then thread the bolts on the flywheel. Most of the time it wont come off with just pure force, so try hitting it with a hammer a cuple times to "vibrate" the thing off. I wish luck to you and ur rotary project!
Marek is offline
Reply With Quote
Old 10-19-04, 09:53 AM
  #6
Full Member
5 Year Member
Thread Starter

Join Date: Jan 2004
Location: north carolina
Posts: 129
Thanks: 0
Thanked 0 Times in 0 Posts
Thumbs up

Thanks For All The Info! I Do Have Air Tools So Maybe It Will Just Fall Off
werd is offline
Reply With Quote
Old 10-19-04, 10:12 AM
  #7
Senior Member
5 Year Member

Bolox's Avatar

Join Date: Mar 2004
Location: Perth, Aus.
Posts: 442
Thanks: 0
Thanked 0 Times in 0 Posts
dont try to heat it with spark plugs, sump plug, and oil filler cap on... one of my mates nearly lost an eye... and he had a HUGE bruise on his head for about a week...


excelent
Bolox is offline
Reply With Quote
Old 10-19-04, 10:35 AM
  #8
Never Follow
iTrader: (18)

82transam's Avatar

Join Date: Feb 2002
Location: North Jersey
Posts: 8,211
Thanks: 0
Thanked 9 Times in 9 Posts
iirc its 54mm, I bought teh giant train sized wrench from mazdatrix, along with the stopper that holds it from moving. A little pb blaster and some muscle later and off it came. As stated earlier I left the nut on loosly and smacked the flywheel loose that way. Piece of cake, well sort of....
82transam is offline
Reply With Quote
Old 10-19-04, 11:08 AM
  #9
My FSP Fiesta eats Jettas
10 Year Member

Wankelguy's Avatar

Join Date: Aug 2002
Location: Springfield, OR
Posts: 1,613
Thanks: 0
Thanked 0 Times in 0 Posts
Yes, it's 54mm.
Wankelguy is offline
Reply With Quote
Old 10-19-04, 11:21 AM
  #10
Rotary Madness
iTrader: (2)

rxtasy3's Avatar

Join Date: Jun 2002
Location: Spartanburg, SC
Posts: 7,105
Thanks: 0
Thanked 36 Times in 35 Posts
i assume all these ppl that ask what size that nut is don't own or have access to a tape measure. i use a 2 1/8" socket.
rxtasy3 is offline
Reply With Quote
Old 10-19-04, 04:05 PM
  #11
Lapping = Fapping
iTrader: (12)

Jeff20B's Avatar

Join Date: Aug 2001
Location: Near Seattle
Posts: 15,501
Thanked 30 Times in 28 Posts
54mm and I use a 2 1/8" impact socket.
Jeff20B is offline
Reply With Quote
Old 10-19-04, 05:19 PM
  #12
0000-09-0233
5 Year Member

SS124A's Avatar

Join Date: Jun 2003
Location: Fort Wankel
Posts: 1,317
Thanks: 0
Thanked 0 Times in 0 Posts
After changing countless numbers of clutches/flywheels I purchased a ring gear brake....

it is likely the best ~$30 Ihave ever spent.
SS124A is offline
Reply With Quote
Old 10-19-04, 07:28 PM
  #13
Banned. I got OWNED!!!

gonzz's Avatar

Join Date: Mar 2002
Location: Las Vegas, NV
Posts: 4,236
Thanks: 0
Thanked 0 Times in 0 Posts
I had a hell of a time removing the flywheel nut before i bought a compressor. Now it's so easy...
gonzz is offline
Reply With Quote
Old 10-20-04, 12:35 AM
  #14
So little time and money

1984special's Avatar

Join Date: Feb 2003
Location: NorCAL
Posts: 746
Thanks: 0
Thanked 0 Times in 0 Posts
freaking huuuuuge.

my friend and I took a blown motor it to sears and they zipped it off for us.
1984special is offline
Reply With Quote
Old 10-20-04, 02:42 AM
  #15
Old Fart Young at Heart
10 Year Member
iTrader: (6)

trochoid's Avatar

Join Date: Apr 2004
Location: St Joe MO
Posts: 15,147
Thanks: 0
Thanked 0 Times in 0 Posts
I've gotten the flywheel nut off easier than the front nut sometimes. And yes, air is the only way to go.
trochoid is offline
Reply With Quote
Old 10-20-04, 08:36 PM
  #16
Never Follow
iTrader: (18)

82transam's Avatar

Join Date: Feb 2002
Location: North Jersey
Posts: 8,211
Thanks: 0
Thanked 9 Times in 9 Posts
that is true, the nut to remove the front pully is a royal pain.
82transam is offline
Reply With Quote
Old 10-21-04, 03:39 AM
  #17
Lapping = Fapping
iTrader: (12)

Jeff20B's Avatar

Join Date: Aug 2001
Location: Near Seattle
Posts: 15,501
Thanked 30 Times in 28 Posts
Oh please. You've never worked on a 20B. (32mm cap nut vs 19mm bolt).
Jeff20B is offline
Reply With Quote
Old 10-21-04, 07:50 AM
  #18
Savanna Rx-7

Join Date: Jun 2004
Location: yokosuka japan
Posts: 1,562
Thanks: 0
Thanked 1 Time in 1 Post
Smile Ahhh poor sing

Jeff, You brought tears to my eyes with that one, He should be so lucky as to have a 20B! Ha!

ken
kenn_chan is offline
Reply With Quote
Old 02-02-06, 04:26 PM
  #19
wheres my calculus book?
5 Year Member

gmanuser's Avatar

Join Date: Jan 2006
Location: st. george UT
Posts: 276
Thanks: 0
Thanked 0 Times in 0 Posts
ahh my good lad i once to had this same problem but overcame it with a big fight ehehhe
what you will need to remove the flywheel is as fowlows
1. 2 1/8 inch socket *
2. probally a 1/2 to 3/4 inch converter unless you already have a 3/4 wrench
3. a 5 pound sludge
4. a air compressor with at least 50 psi or around that
5. a flywheel remover
6. 2 normal strength wahsers (about 1")**
7. 2 thick strong washers (about 1")**
8. saftey glasses!!!!
9. a work rag / old towel
10. 1 medium sized rubber band (heheheh)

*some advice about where to get the socket
- I spent the better part of one day running around town and calling places trying to find the bloody thing, i went to
-ace
-napa
-checker autozone
-mechinical shops
and they all said they dont have them so i eventually found one at my local sears store for 22$ and the adapter for it thier to!

**note that these washers will in all likely hood be bent and ruined by the time you are done.

what i did was
I. take off the flywheel nut via the socket + air compressor + adaptar

A. unscrew the bolt via air gun + socket + adapter

B.now here comes the tricky part, get your flywheel remover tool out and put your washers onto the two long bolts that hold the device onto the flywheel

C. screw on your two bolts that came with the flywheel remover tool onto the flywheel and postion the tool so that the bigest longest bolt of them all comes down and pushes on the verry middle of the engine and the flywheel (thier is a long circular hole in the middle of the flywheel this is where that bolt belongs be sure that it does not catch on the flywheel).

D. (this is where i almost lost my eye because a bolt broke and went flying in our little garage bouncing off crap it barly missed my eye) first thing first before you start tighting the tool down be sure to put on your safty glasses incase of an emengency!!! grab your washers that are about 1" and put each one of your 2 normal washers onto your smaller length bolts where the meat the "structrual brace" aka about 1" thick peace of metal that all the bolts go onto (1 for each) than place your two big strong ones that ar eabout 1" into the very middle where the longest bolt goes and start to screw your longest bolt on by hand***** note the key word of hand**** to just get it hand tight and lines up for when you actually start screwing into it

E. use your air tool to start screwing in the longest bolt in the middle of the flywheel remover, go intill it stops turning or barly turns (turns about 1/8 or so mabe and not much more)

F. now use your sledge and wrap your rag around its head and use a rubber band to keep it on (so you dont hurt the flywheel)

G. wack away hitting the flywheel (dont hit to hard and dont hit the teeth expesiially!!)

H. after a few minutes if no success repeat proccess's E-G




This is how i managed to remove the flywheel!!! i promise that putting it back on is a thosand times easir and less of a hassel, I also realize that i baby steped you threw all of this in hopes of helping everyone!! not just the advnaced people but also the begginers!!! We all need to learn sometime, why not now?
gmanuser is offline
Reply With Quote
Old 02-04-06, 12:07 PM
  #20
wheres my calculus book?
5 Year Member

gmanuser's Avatar

Join Date: Jan 2006
Location: st. george UT
Posts: 276
Thanks: 0
Thanked 0 Times in 0 Posts
sorry for whriting so much but i knew what would come next lol and i figured might as well tell you now
gmanuser is offline
Reply With Quote
Old 05-03-15, 02:17 PM
  #21
Can Post Only in New Member Section

Join Date: Feb 2012
Location: Portland, OR
Posts: 1
Thanks: 0
Thanked 0 Times in 0 Posts
noticed this was a over a decade old but once you back the nut away a good 1/4 " or so grad a 5lb sludge and give it a whack on the outter edge on the non disk surface and is should come right off. The shaft the flywheel is on is tapered, so all it needs is to be knocked loose.
rxr8d is offline
Reply With Quote
Old 05-03-15, 06:37 PM
  #22
Censored
iTrader: (14)

Join Date: Jul 2002
Location: usa
Posts: 10,356
Thanks: 0
Thanked 4 Times in 4 Posts
ray green is offline
