MD Removing the rats nest on a 13b EGI

Hey everyone,

I'm new to the rotary game I just bought a 85 GSL-SE and would like to start removing all of the emissions junk. Is there a step-by-step how to do this? I have been able to find instructions for removing the nest on a 12a.
Old 05-21-15, 09:59 AM
  #2
Doritos & Dual Sports

iTrader: (8)

Sh00bs's Avatar

Join Date: Jun 2013
Location: Pasadena, MD
Posts: 1,082
Received 16 Likes on 13 Posts
Originally Posted by lefty18
Hey everyone, I'm new to the rotary game I just bought a 85 GSL-SE and would like to start removing all of the emissions junk. Is there a step-by-step how to do this? I have been able to find instructions for removing the nest on a 12a.
Did you try searching?
Welcome btw, I suggest making a new member intro post

First post can't give you slack, just remember to search the site first, then google, and if you still can't find it then post the question up
Some of the old timers get oissed after seeing the same questions (I.e. what can I do to make my fb faster?) over and over again
Attached Thumbnails Removing the rats nest on a 13b EGI-image-306654363.jpg
Old 05-21-15, 10:13 AM
  #3
1st Gens are the Best

iTrader: (2)

andernamen's Avatar

Join Date: Apr 2012
Location: Virginia Beach
Posts: 560
Likes: 0
Received 0 Likes on 0 Posts
There are only a few things you can get rid of if you are keeping the EGI system. The air control valve and air pump can go but you will likely need a dual sheave pulley on your alternator or a yoohoo belt. Two solenoids on the firewall attached to the ACV can also be eliminated. The stock exhaust and catalytic converter can go, but depending on your set-up you will lose the 5th and 6th ports (a pre-silencer from racing beat lets you keep them). All the other items in the rats nest are pretty much a necessity to run the stock EGI system. Welcome and good luck.
Old 05-21-15, 10:18 AM
  #4
Out In the Barn


iTrader: (9)

KansasCityREPU's Avatar

Join Date: Mar 2005
Location: KC
Posts: 6,055
Received 1,015 Likes on 801 Posts
Should be noted, if you remove the air pump, you will also need to remove the catalytic convertor and go with a header.
Old 05-21-15, 10:26 AM
  #5
Moderator

iTrader: (3)

j9fd3s's Avatar

Join Date: Mar 2001
Location: https://www2.mazda.com/en/100th/
Posts: 30,832
Received 2,603 Likes on 1,847 Posts
there really isn't a "rats nest" on a gsl-se, there are just two solenoids on the firewall and the ACV. the stuff on the engine is for the idle control and the fuel pressure regulator, and you want that.
Old 05-25-15, 08:00 PM
  #6
I have a rotary addiction

iTrader: (18)

NCross's Avatar

Join Date: Jun 2006
Location: Columbia, Tennessee
Posts: 4,815
Received 23 Likes on 22 Posts
All you really need for the car to run is the fuel injector air bleed socket, vacuum advance solenoid, PCV, and fuel pressure regulator vac line. Literally everything else can be removed. Of course youll need to make adjustments to your idle and possibly TPS.
Old 05-26-15, 12:38 PM
  #7
Senior Member


mhr650's Avatar

Join Date: Sep 2013
Location: asheville
Posts: 301
Received 33 Likes on 26 Posts
On my race car I was able to get it down to 2 solenoids, one for the fuel pressure regulator and one for the vacuum advance in the distributor. I also eliminated all of the stuff off of the throttle body and just have a mechanical idle speed adjustment.
Old 05-28-15, 06:28 AM
  #8
Doritos & Dual Sports

iTrader: (8)

Sh00bs's Avatar

Join Date: Jun 2013
Location: Pasadena, MD
Posts: 1,082
Received 16 Likes on 13 Posts
Originally Posted by NCross
All you really need for the car to run is the fuel injector air bleed socket, vacuum advance solenoid, PCV, and fuel pressure regulator vac line. Literally everything else can be removed. Of course youll need to make adjustments to your idle and possibly TPS.
this sounds like a winner mikey, lets tackle it over the weekend
Old 05-28-15, 05:07 PM
  #9
Junior Member
Thread Starter

lefty18's Avatar

Join Date: May 2015
Location: Pasadena
Posts: 1
Likes: 0
Received 0 Likes on 0 Posts
Originally Posted by Sh00bs
this sounds like a winner mikey, lets tackle it over the weekend
That's what I'm thinking as well. Let's get your wheel bearing done and get mine inside it's supposed to rain all weekend
Old 05-29-15, 06:22 AM
  #10
Doritos & Dual Sports

iTrader: (8)

Sh00bs's Avatar

Join Date: Jun 2013
Location: Pasadena, MD
Posts: 1,082
Received 16 Likes on 13 Posts
Originally Posted by lefty18
That's what I'm thinking as well. Let's get your wheel bearing done and get mine inside it's supposed to rain all weekend
get that post count up, go make an intro thread here:
