jimshih

This is from a car with a 13B swap. I don't know if the last owner got this from the 13B car or FC or ??

I can't match the unit or the wire color on the wiring diagram??

I am putting the engine over to a 79 and taking the electronic ignition over also but not sure about what this connector does?
thanks.

gsl-se addict

iTrader: (3)

That ignition appears to be from an '80. If you can find a wiring diagram from an '80, that would probably help. www.iluvmyrx7.com did have wiring diagrams online, but appears to be no longer up. There is a link to the 1980 FSM in the 1st gen FAQs, but from what I remember doesn't have the wiring diagrams in it. Maybe someone with an '80 could tell you. Good luck.

Kent

jimshih

help anybody?


I am putting this setup in 78 car but not sure what goes to the wires??

thanks.
