B6T

iTrader: (2)

I'm just finishing up machining this at work to install on the street-ported S5 13B I'm swapping into my GSL-SE:



I'm interested in seeing what you guys have made for your 7's. I know we're an intelligent bunch, so there's got to be some pretty cool stuff out there... so let's see it!

thunkrd

iTrader: (1)

oo this looks like solidworks..

i made a cup holder... will take pics later

82transam

iTrader: (18)

I'll have to take pics, but I made a subframe to mount my S5 T2 in my FB using the center iron mounts as if it were still in a FC, that came out pretty nicely. Wish I could machine things though..

DivinDriver

iTrader: (15)

I made some safety-orange parking pillars, to keep the wife from hitting the -7 in the garage... made from "fun-noodles."

OneRotor

iTrader: (3)

Making a lightweight flywheel for yourself? I hope that you have a scatter shield just in case.

tallbozo

iTrader: (5)

A Roll-Pan for my RX7

perfect_circle

and propper counterweight.

Sgt Fox

iTrader: (3)

I made a bracket for my 2stroke reservoir.

DivinDriver

iTrader: (15)

I made an extended exhaust bracket for my resurrected -from-busted-bits stock exhaust:


And a replacement air-pipe sealing washer, from sheet stock:

B6T

iTrader: (2)

I ran FEA on the design and it's well within safety limits, but I was thinking of putting a shield in for extra insurance. The material I'm using is the same as aftermarket parts, and the design isn't much different...

Have it.

orion84gsl

iTrader: (5)

I made a mount for my Holley FPR, to position it away from the pinch weld. I need to redo it in the next couple weeks since the original one was made from pretty thin steel. I have thicker stuff at home and now I know what I'm going for so it should be easier. You can kind of see it towards the passenger side on the firewall.

openshot

custom bodykit

7aull

iTrader: (2)

ni-i-i-i-ice work Sarge! Looks OEM, which is about as high a compliment as I can give

Stu Aull
80GS
Alaska

82transam

iTrader: (18)

I agree, that 2 stroke tank bracket looks great! Some of the other stuff on here does too, guess we have some talented metalworkers on here.

blackdeath647

iTrader: (2)

+1 on the premix container. that looks awesome, how did you manage to get a pump that will premix the right amount for our cars?

rxtasy3

iTrader: (2)

there's a mod for the OMP that allows the use of an external tank.

Sgt Fox

iTrader: (3)

Thank you guys, there is a write-up in the archives: https://www.rx7club.com/1st-gen-archive-71/engine-richard-sohn-metering-pump-adapter-install-810299/

Mickster

iTrader: (2)

Ingenious! Dude, you got skills.

Thanks a bunch Sarge for hosting all the manuals.

vipergts_3

iTrader: (9)

i made lower quarters for my rx7

Sgt Fox

iTrader: (3)

Lets see some pictures mang!

DivinDriver

iTrader: (15)

I made a sunroof storage bag for my spare roof; I worked into it web straps and grommets that allow it to hang on the garage wall:

Sgt Fox

iTrader: (3)

I really like that. Good job.

DivinDriver

iTrader: (15)

I'm considering taking it to an embroidery place, and getting the RX-7 logo (the one on the front quarter) done on the flap in silver. Probably only cost a few bucks.

robs_seven

iTrader: (1)

I made this center console for my cd player and for my gauges, I still have not finished it around the shifter or around the heater controls, but it works. I cut the stainless with a plasma cutter then punched the holes and slots with a punch press.



I also designed and made this carb hat, and ducted it toward the front with a K&N filter. I designed it in Solid Works and transfered it to Surf Cam to program it for a 3 Axis CNC. I cut it on a OKK out of a solid piece of aluminum.



I made a water temp sensor manifold to hold my water temp sensor. I made this style and also made a style for the heater hose for some one else. I turned them on a manual lathe and drilled and tapped them on a mill.

robs_seven

iTrader: (1)

Has no one else made custom stuff for their car? I figured this thread would end up huge
