over 400hp with stock engine + T04S
#1
Full Member
Thread Starter
Join Date: Mar 2002
Location: SWEDEN
Posts: 113
Likes: 0
Received 0 Likes
on
0 Posts
over 400hp with stock engine + T04S
What do you guys think about this??
does it seem to be possible or is it not possible?
Hp: 442 @5940
Ft/lbs:399 @5769
Its on a stock short block 13b-rew engine never rebuilt!
And this is what we used.
HKS T04S kit
Greddy FMIC
Upprated fuel pump
1600cc sec inj
+ much more things
__________________
does it seem to be possible or is it not possible?
Hp: 442 @5940
Ft/lbs:399 @5769
Its on a stock short block 13b-rew engine never rebuilt!
And this is what we used.
HKS T04S kit
Greddy FMIC
Upprated fuel pump
1600cc sec inj
+ much more things
__________________
#5
Full Member
Thread Starter
Join Date: Mar 2002
Location: SWEDEN
Posts: 113
Likes: 0
Received 0 Likes
on
0 Posts
ok this is what i remember that i installd in that car!
HKS T04S TURBO
HKS 50 MM RACING WASTEGATE
HKS EXHAUST MANIFOLD
HKS 3" DOWNPIPE
K&N INTAKE FILTER
GREDDY FMIC
GREDDY IC PIPE KIT
GREDDY ELBOW
GR RELOCATION BATTERY KIT
RE FUEL RAIL
1600CC INJECTOR
SARD FPR
HS FUEL PIPE
UPRATED FUEL PUMP
APEXI POWER FC
APEXI AVC-R
3 BAR MAPSENSOR
GR HOSE LINES
GR POLISHED U.I.M
OSGIKEN TWINPLATE
LIGHT PULLEY KIT
TIAL 50MM BOV
REDLINE ENGINE OIL
REDLINE TRANNY OIL
REDLINE DIFF OIL
I think this was it.
HKS T04S TURBO
HKS 50 MM RACING WASTEGATE
HKS EXHAUST MANIFOLD
HKS 3" DOWNPIPE
K&N INTAKE FILTER
GREDDY FMIC
GREDDY IC PIPE KIT
GREDDY ELBOW
GR RELOCATION BATTERY KIT
RE FUEL RAIL
1600CC INJECTOR
SARD FPR
HS FUEL PIPE
UPRATED FUEL PUMP
APEXI POWER FC
APEXI AVC-R
3 BAR MAPSENSOR
GR HOSE LINES
GR POLISHED U.I.M
OSGIKEN TWINPLATE
LIGHT PULLEY KIT
TIAL 50MM BOV
REDLINE ENGINE OIL
REDLINE TRANNY OIL
REDLINE DIFF OIL
I think this was it.
#6
development
Originally Posted by ABIEX
What do you guys think about this??
does it seem to be possible or is it not possible?
Hp: 442 @5940
Ft/lbs:399 @5769
Its on a stock short block 13b-rew engine never rebuilt!
And this is what we used.
HKS T04S kit
Greddy FMIC
Upprated fuel pump
1600cc sec inj
+ much more things
__________________
does it seem to be possible or is it not possible?
Hp: 442 @5940
Ft/lbs:399 @5769
Its on a stock short block 13b-rew engine never rebuilt!
And this is what we used.
HKS T04S kit
Greddy FMIC
Upprated fuel pump
1600cc sec inj
+ much more things
__________________
if this isn't at the wheels (375rwhp with 340rwtq...still seems like a lot of torque)...It's be more believable if the hp was at 6940...
#7
NASA geek
iTrader: (2)
yeah, the torque numbers and RPM's don't sound like a rotary at all. Something is fishy about those numbers although I've seen T04S 13b's make 400 at the wheels with stock ports, torque should be way lower, RPM should be higher and HP sounds awfully high as well. This is on a engine stand or at the wheels??
~Mike..........
~Mike..........
Trending Topics
#8
Full Member
Thread Starter
Join Date: Mar 2002
Location: SWEDEN
Posts: 113
Likes: 0
Received 0 Likes
on
0 Posts
It is tested on a chassi dyno so the power is near 375whp 340wtq thats right...
but I wrote 1,2 bar all the way upp to 5700rpm and then lower boost upp to 7000rpm.
The ignition is still safe and a lot of fuel after 5700rpm...
All I wanted is to achive high peak hp and Tq at the same point but in the same time the graph should be rising all the way upp to the peak power output.
Iam going to put a dyno chart on the thread later on today and maybe in fewdays later a smal movie..
keep on posting on this thread cause I would like to no your opinion.
but I wrote 1,2 bar all the way upp to 5700rpm and then lower boost upp to 7000rpm.
The ignition is still safe and a lot of fuel after 5700rpm...
All I wanted is to achive high peak hp and Tq at the same point but in the same time the graph should be rising all the way upp to the peak power output.
Iam going to put a dyno chart on the thread later on today and maybe in fewdays later a smal movie..
keep on posting on this thread cause I would like to no your opinion.
#9
rebreaking things
Join Date: Apr 2006
Location: Manhattan
Posts: 866
Likes: 0
Received 0 Likes
on
0 Posts
Hi Abiex:
That sounds really high to me. I haven't looked at a T04S map since I was thinking of buying one about 1.5-2 years ago, but I believe the efficiency drops off pretty fast above 57lbs/min at that boost level. The compressor map of the T04S is similar to the 35R that I had. I have witnessed several cars dyno with the 35R on stock and ported motors at different dyno shops. Most of them came in at or under 410rwhp at 15psi.
Off Topic: How is the SM4 on the 20b working out? I have another option for you if you're not happy with it
That sounds really high to me. I haven't looked at a T04S map since I was thinking of buying one about 1.5-2 years ago, but I believe the efficiency drops off pretty fast above 57lbs/min at that boost level. The compressor map of the T04S is similar to the 35R that I had. I have witnessed several cars dyno with the 35R on stock and ported motors at different dyno shops. Most of them came in at or under 410rwhp at 15psi.
Off Topic: How is the SM4 on the 20b working out? I have another option for you if you're not happy with it
#10
Rotary Freak
iTrader: (8)
Originally Posted by ABIEX
I wanted is to achive high peak hp and Tq at the same point but in the same time the graph should be rising all the way upp to the peak power output.
Last edited by books; 11-27-06 at 08:13 PM. Reason: to edit
#11
Full Member
Thread Starter
Join Date: Mar 2002
Location: SWEDEN
Posts: 113
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by CMonakar
Hi Abiex:
That sounds really high to me. I haven't looked at a T04S map since I was thinking of buying one about 1.5-2 years ago, but I believe the efficiency drops off pretty fast above 57lbs/min at that boost level. The compressor map of the T04S is similar to the 35R that I had. I have witnessed several cars dyno with the 35R on stock and ported motors at different dyno shops. Most of them came in at or under 410rwhp at 15psi.
That sounds really high to me. I haven't looked at a T04S map since I was thinking of buying one about 1.5-2 years ago, but I believe the efficiency drops off pretty fast above 57lbs/min at that boost level. The compressor map of the T04S is similar to the 35R that I had. I have witnessed several cars dyno with the 35R on stock and ported motors at different dyno shops. Most of them came in at or under 410rwhp at 15psi.
Originally Posted by CMonakar
Off Topic: How is the SM4 on the 20b working out? I have another option for you if you're not happy with it
(I put it in a engine dyno) after the thunder strike we tride but it did not want to run good any more... I comp tested it and it seems to have good comp on all rotors.
I am going to try it once again in late feb/2007.....to much work in the new shop right now.
What do you have ??? THE NEW MoTeC ROTARY OPTION ??
#12
Full Member
Thread Starter
Join Date: Mar 2002
Location: SWEDEN
Posts: 113
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by books
I'm not certain what you mean by "high peak" hp, but hp and tq are equal at 5,252 rpms by def.
#13
Full Member
Thread Starter
Join Date: Mar 2002
Location: SWEDEN
Posts: 113
Likes: 0
Received 0 Likes
on
0 Posts
And I forgot to write that its very lean tuned but without any knocks at all.
the gasolin that we used is shell V-power 99 octane.
I spoke to diffrent tuners "just to be shore about this" and told them exactly everything.... It seems to be possible ....
the gasolin that we used is shell V-power 99 octane.
I spoke to diffrent tuners "just to be shore about this" and told them exactly everything.... It seems to be possible ....
#14
development
Originally Posted by CMonakar
I have witnessed several cars dyno with the 35R on stock and ported motors at different dyno shops. Most of them came in at or under 410rwhp at 15psi.
Originally Posted by ABIEX
It is tested on a chassi dyno so the power is near 375whp 340wtq thats right...
looks like boost builds kind of slow, and that terrible spike at 5750.
I think if you control the boost and hold 1.2bar until 7500rpm you'll find about what Chris suggests...410rwhp with ~ 340rwtq <--which look like 13B #'s
(480hp on a stock motor ain't bad )
#17
development
Originally Posted by NeedFD
what a/r is that t04s? compressor and exhaust? something seems strange
Originally Posted by GUITARJUNKIE28
anyone else notice the graphs don't cross?
dyno was fucked up.
dyno was fucked up.
#18
multipersonality disorder
Join Date: Feb 2002
Location: so. cal
Posts: 5,656
Likes: 0
Received 0 Likes
on
0 Posts
if they were measured in different units, maybe...
but torque = hp @ 5252. something was wrong with that.
the only other way i can think of to get that kind ot tq:hp ratio on a 2-rotor is to boost the **** out of it down low, but then taper the boost way off up top. that's why i originally asked if the boost rolled off up top.
but fucked up dyno or no, i'm sure it's a fast car
but torque = hp @ 5252. something was wrong with that.
the only other way i can think of to get that kind ot tq:hp ratio on a 2-rotor is to boost the **** out of it down low, but then taper the boost way off up top. that's why i originally asked if the boost rolled off up top.
but fucked up dyno or no, i'm sure it's a fast car
