50mm wastegate?
#3
That's what she said...
iTrader: (2)
Join Date: Jul 2005
Location: Socal
Posts: 572
Likes: 0
Received 0 Likes
on
0 Posts
thrust
Originally Posted by Rx7phil
Is a 50mm wastegate big enough for a T-78 turbo at about 15psi??
Thnx
Thnx
That will handle anything you throw at it. I have the THRUST "greddy" 50mm wastegate and no boost spike what so ever..
#7
That's what she said...
iTrader: (2)
Join Date: Jul 2005
Location: Socal
Posts: 572
Likes: 0
Received 0 Likes
on
0 Posts
for the both of you
Originally Posted by diabolical1
LOL that's why i asked. i was hoping to leech off of your thread in order to shed some light on that same question.
Trending Topics
#8
Big Snail
I'm running the HKS standard 40mm and i'm having spiking problems. Gonna eventually switch to the Turbonetics NewGen wastegate.
Last edited by 93FD3S; 10-06-06 at 01:36 PM.
#11
91 TII JDM
Join Date: Aug 2004
Location: Portland, OR
Posts: 47
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by Rx7phil
I was planning a SSautochrome 50mm wastegate. Do you think itll be alright??
no
Like (mostly) everything in the world, what you pay for is what you get. It's worth getting a $200-300 wastegate to insure that it will actually work for more then a week.
#12
DETH TRP
iTrader: (7)
Join Date: Mar 2004
Location: Manhattan Beach, CA
Posts: 2,544
Likes: 0
Received 0 Likes
on
0 Posts
actually go ahead and buy the SSA wastegates and then replace the spring(s) with name brand parts.
This is what i planned to do with the 60mm HKS ripoff they offer. The housings will hodl up just fine but if the springs are made incorrectly or of cheaper material they may fail under high temps.
Many guys have been using the generic/name brand combo I described above.
Sure beats paying $1000 for a true HKS 60mm!
This is what i planned to do with the 60mm HKS ripoff they offer. The housings will hodl up just fine but if the springs are made incorrectly or of cheaper material they may fail under high temps.
Many guys have been using the generic/name brand combo I described above.
Sure beats paying $1000 for a true HKS 60mm!
#13
Full Member
Thread Starter
Join Date: Mar 2005
Location: Quebec, Canada
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by 4CN Air
actually go ahead and buy the SSA wastegates and then replace the spring(s) with name brand parts.
This is what i planned to do with the 60mm HKS ripoff they offer. The housings will hodl up just fine but if the springs are made incorrectly or of cheaper material they may fail under high temps.
Many guys have been using the generic/name brand combo I described above.
Sure beats paying $1000 for a true HKS 60mm!
This is what i planned to do with the 60mm HKS ripoff they offer. The housings will hodl up just fine but if the springs are made incorrectly or of cheaper material they may fail under high temps.
Many guys have been using the generic/name brand combo I described above.
Sure beats paying $1000 for a true HKS 60mm!
#15
so ...no time for this
interesting, I had a SS 50mm about 2 years from now, never had a single problem until boosted over 26... i was thinking on the temps since pressure only drops when racing (very hot) but was pointing on the boost controller... i'll replace the spring and see how it goes....
Originally Posted by 4CN Air
actually go ahead and buy the SSA wastegates and then replace the spring(s) with name brand parts.
This is what i planned to do with the 60mm HKS ripoff they offer. The housings will hodl up just fine but if the springs are made incorrectly or of cheaper material they may fail under high temps.
Many guys have been using the generic/name brand combo I described above.
Sure beats paying $1000 for a true HKS 60mm!
This is what i planned to do with the 60mm HKS ripoff they offer. The housings will hodl up just fine but if the springs are made incorrectly or of cheaper material they may fail under high temps.
Many guys have been using the generic/name brand combo I described above.
Sure beats paying $1000 for a true HKS 60mm!
#16
so ...no time for this
if srpings hold you might have a boost contro problem...or your WG is to big/small for your a/r ratio,,, did you tried connecting the WG boost signal line to open the valve withou any control device?
Originally Posted by APEXL8T
I did that , and today its over boosting even with a 14bls HKS spring and HKS diaphram.
Still boosting crazy 20...
Cant find a leak anywhere yet.
Still boosting crazy 20...
Cant find a leak anywhere yet.
#18
boxed in and drawn out
Join Date: Dec 2003
Location: Bayouself
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by AImec Racing
if srpings hold you might have a boost contro problem...or your WG is to big/small for your a/r ratio,,, did you tried connecting the WG boost signal line to open the valve withou any control device?
No luck. It opens @7lbs and will spike to 17+ . We got off because I didnt have the 3 bar connected. I want to get the PFC to tuned to the stock MAp sensor but I can get on the car because of this big spike issue.I wouldnt even call this a spike..it justgoes.We did remove the spring to put in the HKS spring. Same.I have been breaking the motor in but not allowing boost over 7.
#20
boxed in and drawn out
Join Date: Dec 2003
Location: Bayouself
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
What the hell.
Inlet and outlet are 2". No leaks in cap. Nothing connected to wastegate and it still runs off the charts......
How can this size orifice be TOO SMALL?I would hate to spend $900.00 on a Greddy 60mm if it is something else.the wastegate spring is opening at 10lbs.
Inlet and outlet are 2". No leaks in cap. Nothing connected to wastegate and it still runs off the charts......
How can this size orifice be TOO SMALL?I would hate to spend $900.00 on a Greddy 60mm if it is something else.the wastegate spring is opening at 10lbs.
#21
Pineapple Racer
iTrader: (1)
On my HKS, and a friends of mines.....they where "sticky" from the factory. I had to have the guide honed out just a hair on mine...as did my buddy. I had my 50mm HKS overboost me to 23lbs a year or two ago. I about crapped my pants! I should have listened to Ralph@Groundzero and bought a tial. Only reason I did'nt was because I would have had to change the flange. Stupid on my part. CJ
#24
Originally Posted by APEXL8T
What the hell.
Inlet and outlet are 2". No leaks in cap. Nothing connected to wastegate and it still runs off the charts......
How can this size orifice be TOO SMALL?I would hate to spend $900.00 on a Greddy 60mm if it is something else.the wastegate spring is opening at 10lbs.
Inlet and outlet are 2". No leaks in cap. Nothing connected to wastegate and it still runs off the charts......
How can this size orifice be TOO SMALL?I would hate to spend $900.00 on a Greddy 60mm if it is something else.the wastegate spring is opening at 10lbs.
With the 60mm I get soild boost control from 9 psi to 40 psi.
BTW. The Greddy Type CH is 58mm. The HKS GT is 60mm and the GT2 is either 50 or 60mm.
Check out the 55 and 62mm wastegates on this page. Anyone ever use or heard anything about them?
http://www.capa.com.au/turbo_wastegates.htm
Now for replicator central-->
This one looks like a HKS GT2 copy-->
http://www.theturboshop.com.au/index...6a6736b3037a2f
The same as above--> http://www.xo2racing.com/cart/produc...s7s43rbkthue95
The one on the bottom of this page 'looks' to be an exact copy of the HKS GT2.->
http://www.ssautochrome.com/level.itml/icOid/1544
And off course the E-Bay special-->http://cgi.ebay.com/ebaymotors/60mm-...QQcmdZViewItem
Last edited by crispeed; 10-22-06 at 01:50 AM.
#25
boxed in and drawn out
Join Date: Dec 2003
Location: Bayouself
Posts: 555
Likes: 0
Received 0 Likes
on
0 Posts
You might just have too. On my big street port motors I cannot use anything smaller than the 60mm. I've tried everything else and always the same results... boost creep.
With the 60mm I get soild boost control from 9 psi to 40 psi.
BTW. The Greddy Type CH is 58mm. The HKS GT is 60mm and the GT2 is either 50 or 60mm.
*****************************************
Thanks,
I guess thats why we a re seeing two 38's now. What do the guys withthe GT42 use?
I cant imagine all these years big turbo and street ports everyone has been having creep issues. I guess I will need the larger better wastegate.
Now my issue is the cast iron HKS header has a square flange.
I would like this forever project to come to an end for enjoyment. I am closer ...
l8t
With the 60mm I get soild boost control from 9 psi to 40 psi.
BTW. The Greddy Type CH is 58mm. The HKS GT is 60mm and the GT2 is either 50 or 60mm.
*****************************************
Thanks,
I guess thats why we a re seeing two 38's now. What do the guys withthe GT42 use?
I cant imagine all these years big turbo and street ports everyone has been having creep issues. I guess I will need the larger better wastegate.
Now my issue is the cast iron HKS header has a square flange.
I would like this forever project to come to an end for enjoyment. I am closer ...
l8t
