Clutch disengagement 300 miles after replacement

Thread Tools

Search this Thread

Old May 23, 2005 | 10:20 AM
  #26
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
my engagement issue is intermittent and 90% of the time runs/drives/shifts just fine
Reply
Old May 23, 2005 | 10:29 AM
  #27
shawnk's Avatar
Perpetual Rebuilder
Tenured Member 20 Years

Joined: Mar 2002
Posts: 1,250
Likes: 0
From: Seattle, Washington
Originally Posted by BoostFrenzy
my engagement issue is intermittent and 90% of the time runs/drives/shifts just fine
Mine was too...for a week. Then it let go completely. Luckily it was on a lift at the time...

Oh and I added a few more links above...check those out.

Shawn
Reply
Old May 23, 2005 | 10:34 AM
  #28
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
so it ended up being your pilot bearing?
Reply
Old May 23, 2005 | 12:43 PM
  #29
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
hmm checked at lunch mad some rattle at cold startup, disappeared quickly now i don't hear it :/ gremlins!

talked to exedy and they told me if i don't have any engagement or otherwise problems and since it's quiet to not worry about it
Reply
Old May 24, 2005 | 12:19 PM
  #30
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
noise is still there, haven't had any disengagement/engagement problems though, just sounds like rocks in a cofffe can or rod knock with clutch pushed in but car not moving, seems to come and go but always loudest on a cold start

hmm
Reply
Old May 24, 2005 | 01:20 PM
  #31
DigDug's Avatar
Registered User
Tenured Member 05 Years

Joined: Jan 2003
Posts: 1,038
Likes: 0
From: Sterling, VA
If the clutch disengages okay, but you're hearing that noise, sounds like the pilot bearing has disintegrated. Do you feel vibration on the shifter when the clutch is disengaged? And what about when it's engaged?
Reply
Old May 24, 2005 | 01:22 PM
  #32
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
no i don't notice any vibration in the shifter, however the shifter seems to sway a little while driving with the contours of the road/engine movement, figured that normal?

i noticed i can sometimes make the noise louder if i put it in 3rd with the clutch engaged and then push a little harder up as it's already in 3rd
Reply
Old May 24, 2005 | 01:27 PM
  #33
Mahjik's Avatar
Mr. Links
Tenured Member 20 Years
iTrader: (1)

Joined: Aug 2001
Posts: 27,595
Likes: 43
From: Kansas City, MO
You aren't going to be able to troubleshoot anything until you start narrowing down what isn't a problem (i.e. dropping the tranny and inspecting the pilot bearing, throw-out bearing, clutch fork, etc).
Reply
Old May 24, 2005 | 01:35 PM
  #34
DigDug's Avatar
Registered User
Tenured Member 05 Years

Joined: Jan 2003
Posts: 1,038
Likes: 0
From: Sterling, VA
Originally Posted by BoostFrenzy
no i don't notice any vibration in the shifter, however the shifter seems to sway a little while driving with the contours of the road/engine movement, figured that normal?
No, I meant vibration when you hear that "coffee can rattle". When the clutch is disengaged.


Originally Posted by BoostFrenzy
i noticed i can sometimes make the noise louder if i put it in 3rd with the clutch engaged and then push a little harder up as it's already in 3rd
I'd check that input shaft bearing next time you have the trans out...
Reply
Old May 24, 2005 | 01:38 PM
  #35
DigDug's Avatar
Registered User
Tenured Member 05 Years

Joined: Jan 2003
Posts: 1,038
Likes: 0
From: Sterling, VA
Originally Posted by Mahjik
You aren't going to be able to troubleshoot anything until you start narrowing down what isn't a problem (i.e. dropping the tranny and inspecting the pilot bearing, throw-out bearing, clutch fork, etc).
Very true. If it were my car, I'd get the trans out ASAP. I'd bet money it's the pilot bearing (honestly, seems obvious), but you can't be sure until you look...
Reply
Old May 24, 2005 | 01:39 PM
  #36
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
i'm just upset i didn't abuse it and it only went 400 miles now this
Reply
Old May 24, 2005 | 05:27 PM
  #37
Touring FD3S's Avatar
Senior Member
Tenured Member 15 Years

Joined: Feb 2001
Posts: 530
Likes: 0
From: PA
Weird, but I am having the same problem. I pulled the tranny the other day and everything seems to look ok cept for the fact that the shaft has play. Does anyone know of places to get the input shaft bearing?
Reply
Old May 24, 2005 | 06:44 PM
  #38
BoostFrenzy's Avatar
Thread Starter
Avoiding the tree lane
Tenured Member 05 Years

Joined: Mar 2005
Posts: 568
Likes: 0
From: Grand Rapids, MI
i'm pullin it out right now
Reply
Old May 24, 2005 | 08:10 PM
  #39
DigDug's Avatar
Registered User
Tenured Member 05 Years

Joined: Jan 2003
Posts: 1,038
Likes: 0
From: Sterling, VA
Not sure where to get the input shaft bearing online, but a dealership will be able to get it...

Pilot bearing:
http://catalog.drivewire.com/drivewi...=Pilot+Bearing

Pilot bearing seal:
http://catalog.drivewire.com/drivewi...t+Bearing+Seal

Less than $12, plus shipping.
Reply
Old May 24, 2005 | 08:18 PM
  #40
DigDug's Avatar
Registered User
Tenured Member 05 Years

Joined: Jan 2003
Posts: 1,038
Likes: 0
From: Sterling, VA
I'd get the input shaft bearing done by a shop - opening the trans case is where I draw the line for doing the work myself...
Reply
Old May 25, 2005 | 08:36 AM
  #41
shawnk's Avatar
Perpetual Rebuilder
Tenured Member 20 Years

Joined: Mar 2002
Posts: 1,250
Likes: 0
From: Seattle, Washington
I have no lines


Reply
Old May 25, 2005 | 01:01 PM
  #42
DigDug's Avatar
Registered User
Tenured Member 05 Years

Joined: Jan 2003
Posts: 1,038
Likes: 0
From: Sterling, VA
Hehe, nice!
Reply
