96-02 RX7 BLACK BOX (no rats nest)
I recently just bought a complete used engine from Japan but did not expect the 96-02 spec engine, it came with the 16 bit ECU but a damn cut wire harness. Now i dont know what i should do, Im happy with all the updates on the engine especially the black box but could I make this work? It's hard to rewire the harness especially not knowing how the new system operates with the 16 bit ECU
I really want to do this conversion because that new black box looks alot better than that rats nest but is it worth it? WHats difference with the old 8 bit ECU to the 16 bit anyway? Please help.
I really want to do this conversion because that new black box looks alot better than that rats nest but is it worth it? WHats difference with the old 8 bit ECU to the 16 bit anyway? Please help.
03-02-06, 11:11 AM
#3
Solenoids do not run digitally (they don't know 8 bits from 16), so it's entirely possible to splice the harnesses together.
Unfortunately, I don't know of anyone who has any information about the black box connectors or wiring harness. You could probably do it if you got a copy of the vacuum hose diagram for the 96+ system, but it would take some effort and probably isn't worth it.
Dave
Unfortunately, I don't know of anyone who has any information about the black box connectors or wiring harness. You could probably do it if you got a copy of the vacuum hose diagram for the 96+ system, but it would take some effort and probably isn't worth it.
Dave
03-02-06, 08:16 PM
#4
Full Member
Thread Starter
Join Date: Mar 2006
Location: Rancho Cucamonga
Posts: 208
Likes: 0
Received 0 Likes
on
0 Posts
I know the solenoids operate only on voltage on and off so the computer being 16 bit wouldn't matter, i just wanted to know what the 16bit does over the 8 bit. I heard that the ECU controls the black box alot differently since its more of a one piece unit, so im just expecting the worse that this maybe isnt simple as i thought. I do appreciate your infos and advices please keep them coming.
03-02-06, 09:30 PM
#6
What's your point ?
Join Date: Feb 2001
Location: Gainesville, Fla.
Posts: 3,573
Likes: 0
Received 0 Likes
on
0 Posts
What if the black box is bad (only takes one portion of it (one valve not working) and you have to replace the whole thing (kind of expensive for one valve) Hope you can make it work if you go that route.
03-02-06, 09:44 PM
#7
I don't know where you are located.. but I wouldn't worry about using the blk box. Just get a pfc (also 16 bits) and use your old harness.
The problem with Blk box is that if one of the solenoid inside is bad, you will never know which one. It might look simple from outside (and clean) but in the long run, I think its better to go either simplified twins to get rid of some solenoids or just stick with good ole 93-95 USA set up. That's just my opinion though.. you should do what you want to do..
The problem with Blk box is that if one of the solenoid inside is bad, you will never know which one. It might look simple from outside (and clean) but in the long run, I think its better to go either simplified twins to get rid of some solenoids or just stick with good ole 93-95 USA set up. That's just my opinion though.. you should do what you want to do..
