What size turbo(s) to make at least 300 whp?

Thread Tools

Search this Thread

Old 04-19-17, 08:14 PM
  #1
Can Post Only in New Member Section
Thread Starter

Servin_upaces's Avatar

Join Date: Apr 2017
Location: San Diego
Posts: 1
Likes: 0
Received 0 Likes on 0 Posts
What size turbo(s) to make at least 300 whp?

Hey guys, Bare with me this is the first forum I've joined. Just bought an 87 rx7 fc and want to make sure I do everything right the first time. I know I need to get matching injectors, bov, recuirculate, tune etc.. but just talking strictly turbo chargers how big does it need to be to make significant hp? I know it needs to be big. I was going to buy a t28 from an s15 off my buddy I worked with at Nissan and yes you guessed it.. it was going to go on his 240.. (s13). I did my research and I know I would need two so I didn't buy it. Anyways, what turbo(s) should I get? Single vs twin? Just want to do this right!
Old 04-19-17, 08:41 PM
  #2
Rotary Freak

iTrader: (10)

DC5Daniel's Avatar

Join Date: Jul 2012
Location: Peachtree City, GA
Posts: 1,631
Received 83 Likes on 63 Posts
Originally Posted by Servin_upaces
Hey guys, Bare with me this is the first forum I've joined. Just bought an 87 rx7 fc and want to make sure I do everything right the first time. I know I need to get matching injectors, bov, recuirculate, tune etc.. but just talking strictly turbo chargers how big does it need to be to make significant hp? I know it needs to be big. I was going to buy a t28 from an s15 off my buddy I worked with at Nissan and yes you guessed it.. it was going to go on his 240.. (s13). I did my research and I know I would need two so I didn't buy it. Anyways, what turbo(s) should I get? Single vs twin? Just want to do this right!
You have omitted a lot useful information, but your first hurdle is budget.

300whp is not a lot for these cars, but you need to change a lot of things and spend a decent amount of money to make the "jump". Also, almost no one is doing twins on the FC...even FD guys are getting away from twins. A modern single turbo is just as good if not better in most applications.

Strictly referring to the turbocharger, I'd recommend one of three choices:

Cheapest: hybrid turbo. BNR stage 2/3/4 will get you to 300whp.

Budget conscious: Garrett GT35R or comparable Borg Warner SXE.

Price is no option: Borg Warner EFR.
Old 04-20-17, 01:43 AM
  #3
Retired Moderator, RIP

iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,581
Likes: 0
Received 131 Likes on 114 Posts
You may need to make some adjustments..(chuckle) but this one will vastly improve your engine HP..!
Attached Thumbnails What size turbo(s) to make at least 300 whp?-18033127_1873374659585693_5127934842842687991_n.jpg
Old 04-20-17, 01:32 PM
  #4
I Dislike Everything

iTrader: (1)

rowtareh?'s Avatar

Join Date: Apr 2002
Location: St. Louis/Southern Illinois
Posts: 3,701
Likes: 0
Received 7 Likes on 7 Posts
BNR for simplest and bang for your buck. I believe all of their setups use the stock manifold (could be wrong). I have a Stage 2, and it's fine. I'm actually just thinking of sticking with it forever. I don't need or even want +400rwhp. I also like not having to upgrade my ECU and fuel system.
Old 04-20-17, 06:05 PM
  #5
I

iTrader: (6)

KompressorLOgic's Avatar

Join Date: May 2004
Location: Spanaway, WA
Posts: 3,755
Received 12 Likes on 12 Posts
A full 3" exhaust
a bnr stage 3 turbo(hybrid stock turbo)
a front mount intercooler
a walbro 255 fuel pump
4x720cc injectors (or two 720 and two 1200cc)
rtel 2.1 ecu
a proper tune
an upgraded radiator
and u should be able to make 300 easy
Old 04-21-17, 07:16 AM
  #6
Full Member


YoKramer's Avatar

Join Date: Dec 2002
Location: Charlotte NC
Posts: 140
Likes: 0
Received 1 Like on 1 Post
Originally Posted by KompressorLOgic
A full 3" exhaust
a bnr stage 3 turbo(hybrid stock turbo)
a front mount intercooler
a walbro 255 fuel pump
4x720cc injectors (or two 720 and two 1200cc)
rtel 2.1 ecu
a proper tune
an upgraded radiator
and u should be able to make 300 easy
You would think. Ive done all of that except with a Haltech and I put down 250 to the wheels on a Mustang (albeit a known low reading one). Could I have leaned it out a bit and gotten more power? Probably but I like my just under 11 afr for 15lbs of boost.
