High comp rotors in a turbo motor?
09-24-05, 10:32 PM
#1
High comp rotors in a turbo motor?
Hi all- I'm still new to the forum and am trying to learn as much as I can about this most interesting motor and was curious about the compression ratios. Is it 1: possible to put NA rotors in a turbo motor, 2: is it worth the trouble to do so?
I've been thinking that since the combustion chamber 'enlarges' after spark, that the compression wouldnt put as much force on the seals/rotor as hard (as compared to a piston style engine). I figure you'd have to run lower boost to prevent detonation. Would the gain in compression be advantagous (while running lower compression). Any reasonable thoughts or ideas welcome.
Other question- what specifiacally is the difference between the NA and turbo rotors? (pics or a general explination. plz)
I've been thinking that since the combustion chamber 'enlarges' after spark, that the compression wouldnt put as much force on the seals/rotor as hard (as compared to a piston style engine). I figure you'd have to run lower boost to prevent detonation. Would the gain in compression be advantagous (while running lower compression). Any reasonable thoughts or ideas welcome.
Other question- what specifiacally is the difference between the NA and turbo rotors? (pics or a general explination. plz)
09-24-05, 10:40 PM
#2
Fabricator and builder
Join Date: Jun 2003
Location: Innisfil, Ontario
Posts: 936
Likes: 0
Received 0 Likes
on
0 Posts
Yes you can use the na rotors. You'd need the counterbalance to go with them. However the higher compression would probably force you to run less boost, unless you went with a standalone. With the higher compression I think you'd need more accurate tuning than the stock ecu would allow. Just my thoughts. I'm no expert on turbo motors.
09-24-05, 11:14 PM
#5
Passing life by
brent clement - That is not completely accurate but a safe analogy. There is absolutely no reason he can’t run 12psi on stock turbo with it.
You will spool faster and receive more HP at any given rate with a higher compression motor compared to a lower compression motor. The only thing at all that comes into play is that your detonation point is a little bit closer meaning the fuel can knock sooner. So just have the proper setup and you will be fine.
You will spool faster and receive more HP at any given rate with a higher compression motor compared to a lower compression motor. The only thing at all that comes into play is that your detonation point is a little bit closer meaning the fuel can knock sooner. So just have the proper setup and you will be fine.
Trending Topics
09-25-05, 12:43 AM
#8
multipersonality disorder
Join Date: Feb 2002
Location: so. cal
Posts: 5,656
Likes: 0
Received 0 Likes
on
0 Posts
high comp will give you more power per boost level up to the point where the combustion pressure and heat get too high and you start detonating.
it's ideal for low boost (sub 14-17psi on pump gas) situations though...depending on the turbo size, among other factors.
it's ideal for low boost (sub 14-17psi on pump gas) situations though...depending on the turbo size, among other factors.
09-25-05, 02:50 AM
#9
I detonated and blew up my high-compression turbo setup, running 9:4:1 s4 N/A rotors... Not enough fuel, no way to retard timing...
If you're thinking about an affordable and streetable setup, at least get the R-tek 1.7 chip to retard the timing as the boost increases.
14psi only worked for a day...
On a positive note, my buddy who was running a nearly identical setup to mine, is having NO problems with his high-comp setup--he's using the R-tek chip at 12-13psi on the stock turbo, upgraded fuel etc.
If I were to do it again, I'd run it with a standalone ECU.
If you do it, just be careful and don't get TOO boost happy without the proper support.
If you're thinking about an affordable and streetable setup, at least get the R-tek 1.7 chip to retard the timing as the boost increases.
14psi only worked for a day...
On a positive note, my buddy who was running a nearly identical setup to mine, is having NO problems with his high-comp setup--he's using the R-tek chip at 12-13psi on the stock turbo, upgraded fuel etc.
If I were to do it again, I'd run it with a standalone ECU.
If you do it, just be careful and don't get TOO boost happy without the proper support.
09-25-05, 03:26 AM
#14
i am legendary
Join Date: Sep 2003
Location: Kirkland, WA
Posts: 8,478
Likes: 0
Received 0 Likes
on
0 Posts
^^
Yes, but if he was talking about Megasquirt by itself, then no it wont, that'll only control fuel. Not sure if he knows that or if he just didn't want to type out the Spark portion.
Yes, but if he was talking about Megasquirt by itself, then no it wont, that'll only control fuel. Not sure if he knows that or if he just didn't want to type out the Spark portion.
09-25-05, 03:33 AM
#17
i am legendary
Join Date: Sep 2003
Location: Kirkland, WA
Posts: 8,478
Likes: 0
Received 0 Likes
on
0 Posts
I think I confused you. Megasquirt does fuel only, Megasquirt n' Spark does fuel and igntion control
For the people that want to control just fuel and either use stock ECU for igntion or a dizzy, these being the lazy people that cannot set up and tune it themselves, can use just the MS to control fuel rather than the MSnS. The only difference in the MSnS is that it has another connector and is slightly altered for ignition control.
And yes the MSnS now works with rotary thanks to muythaixbr (sp?). He finally got all the coding/programming worked out for it
For the people that want to control just fuel and either use stock ECU for igntion or a dizzy, these being the lazy people that cannot set up and tune it themselves, can use just the MS to control fuel rather than the MSnS. The only difference in the MSnS is that it has another connector and is slightly altered for ignition control.
And yes the MSnS now works with rotary thanks to muythaixbr (sp?). He finally got all the coding/programming worked out for it
09-25-05, 03:35 AM
#18
i am legendary
Join Date: Sep 2003
Location: Kirkland, WA
Posts: 8,478
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by GUITARJUNKIE28
but back to my 35r with the 9.5 rotors mmmmmmm
mmmmmmm
And if I recall, the 9.5:1 compression was because you started with s5 9.7:1 rotors and polished them, right? And they tested out to 9.5 afterwards? Something like that if I'm remembering correclty...
09-25-05, 03:37 AM
#19
multipersonality disorder
Join Date: Feb 2002
Location: so. cal
Posts: 5,656
Likes: 0
Received 0 Likes
on
0 Posts
yea, exactly....or at least as accurately as i can measure the meniscus. but the consistancy is more important than the actual number--which actually could be off. but who cares? it'll work
and **** mazdatrix
and **** mazdatrix
09-25-05, 03:38 AM
#21
multipersonality disorder
Join Date: Feb 2002
Location: so. cal
Posts: 5,656
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by dDuB
I think I confused you. Megasquirt does fuel only, Megasquirt n' Spark does fuel and igntion control
For the people that want to control just fuel and either use stock ECU for igntion or a dizzy, these being the lazy people that cannot set up and tune it themselves, can use just the MS to control fuel rather than the MSnS. The only difference in the MSnS is that it has another connector and is slightly altered for ignition control.
And yes the MSnS now works with rotary thanks to muythaixbr (sp?). He finally got all the coding/programming worked out for it
For the people that want to control just fuel and either use stock ECU for igntion or a dizzy, these being the lazy people that cannot set up and tune it themselves, can use just the MS to control fuel rather than the MSnS. The only difference in the MSnS is that it has another connector and is slightly altered for ignition control.
And yes the MSnS now works with rotary thanks to muythaixbr (sp?). He finally got all the coding/programming worked out for it
i think you read that post before i edited it because i hadn't read your post right above the previous one... i'm getting dizzy LOL
09-25-05, 03:45 AM
#24
Originally Posted by ZeroDrift
Is it 1: possible to put NA rotors in a turbo motor, 2: is it worth the trouble to do so?
For more info check the Rx8club. Those cars run even higher 10.0 compression rotors and are beging turbo charged succesfully. It's all in the tuning.
09-25-05, 03:47 AM
#25
i am legendary
Join Date: Sep 2003
Location: Kirkland, WA
Posts: 8,478
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by t-von
For more info check the Rx8club. Those cars run even higher 10.0 compression rotors and are beging turbo charged succesfully. It's all in the tuning.
Most rx8 owners run about 4.5-5psi from what I've seen, with hardly impressive results. The greddy kit is a piece of junk and the characteristics of the car completely change from what I've heard, the powerband just completely changes and isn't as smooth.
And so far the other turbo kits out there are untested or hard to get ahold of, so there's not much available. There's some guy from puerto rico that's claiming a lot, but never posts pics or anything so it's all talk. Some of the supercharger kits might be better after some testings... The rx8 owners just need more ECU options for controlling everything, like going standalone but keeping the stock ECU to control the ports and such in the manifold.
