Lowering our 1st Gens
raysspl.com
Joined: Sep 2003
Posts: 3,508
Likes: 0
From: L.A.
Rotary Freak
Joined: Aug 2001
Posts: 2,267
Likes: 3
Springs? I have Racing Beat springs all the way around, for a modest 1-inch drop. I have also used a Ground Control coil-over front suspension with their specially wound dead-coil rear springs (there are several "dead" coils that can be cut off without affecting the rate).
Trending Topics
Rotary Enthusiast
Joined: Jul 2002
Posts: 896
Likes: 0
From: CA
I'll be honest i have no idea why it wouldn't be a good idea, but more that i've never seen any solid axle front or rear ends use a coilover setup. The coilover setup has it's advantage in inpendant suspension systems. I believe it has a lot to do with how the axle moves up and down as a unit etc...
Senior Member
Joined: Nov 2003
Posts: 468
Likes: 1
From: Victoria, BC, Canada
coilovers:
http://www.wankelkim.net/rx7/fb/rearsusp(1).JPG
This is on an ex two times Danish Championship Roadrace FB so I'd say it works pretty well. This was originally posted in Race Car Tech by Kim. I also believe that 680RWHP has coilovers in the rear as well except his car is build for drag so it is probably significantly different. If you are running in a class with few rules then this would probably be an excellent set-up, but waaay overkill on the road.
Grant
http://www.wankelkim.net/rx7/fb/rearsusp(1).JPG
This is on an ex two times Danish Championship Roadrace FB so I'd say it works pretty well. This was originally posted in Race Car Tech by Kim. I also believe that 680RWHP has coilovers in the rear as well except his car is build for drag so it is probably significantly different. If you are running in a class with few rules then this would probably be an excellent set-up, but waaay overkill on the road.
Grant
Senior Member
Joined: Jun 2003
Posts: 352
Likes: 0
From: Canada
The only reason I know of for not using coil overs is that a shock mount is not as sturdy. So if you have a rusted body you may send the coil-over right through the body.
Also if you're getting bouncieness with cut springs it prbably just means your shocks are no longer set up for the new range of motion of that spring.
Also if you're getting bouncieness with cut springs it prbably just means your shocks are no longer set up for the new range of motion of that spring.
Thread Starter
Joined: May 2004
Posts: 1,366
Likes: 10
From: Drifting a Roundabout near you!
Grantmac, thanks for the link! That was a tight setup with the coilovers and the panhard. Then Panhard has been on my mind for about 6 months and this was the best pics I have seen on a install.
http://www.wankelkim.net/rx7/fb
http://www.wankelkim.net/rx7/fb
Senior Member
Joined: Nov 2003
Posts: 468
Likes: 1
From: Victoria, BC, Canada
Well that panhard is kinda screwed up. Keep in mind that this isn't my car. There is a pretty good discussion of that rear-end set-up in the Race Car Tech under "I just bought a 13B PP racecar" or something like that. It may actually be an equal-length watts link that you're looking at.
Grant
Grant
I hate because I'm bored.
Joined: Sep 2003
Posts: 510
Likes: 0
From: Fort Collins, CO
Only reason that comes to my mind for not using a solid axle with coilovers is the "GM Effect". In the 60's GM built several cars with coilovers and solid axles. They had this strange habit of "floating" the car out from on top of the axle in cornering, resulting in the axle whipping back into place.
Subsequently they are my grandfather's choice for a drift car. He maintains that RX-7s and 240SXs are far too small and nimble to be good for drifting, and that his 60 Cadillac convertible was the ideal drift car because it had the above mentioned suspension.
Subsequently they are my grandfather's choice for a drift car. He maintains that RX-7s and 240SXs are far too small and nimble to be good for drifting, and that his 60 Cadillac convertible was the ideal drift car because it had the above mentioned suspension.
G-force engineering "red dot" rears springs will slam the back and ground control coil-overs for the front with eibach race springs. thats all you need. i'll get pics of mine hopefully in the next couple of weeks to show you
That's Weak Sause
Joined: May 2004
Posts: 464
Likes: 0
From: Idaho
Coil Overs/Solid axle
Originally Posted by RX7Elmo
I'll be honest i have no idea why it wouldn't be a good idea, but more that i've never seen any solid axle front or rear ends use a coilover setup. The coilover setup has it's advantage in inpendant suspension systems. I believe it has a lot to do with how the axle moves up and down as a unit etc...
1983 GSL, 1987 323 "GX"
Joined: Jun 2004
Posts: 2,265
Likes: 0
From: Las Cruces, NM
Mine's lower, by a LOT (probably about an inch, maybe an inch.5), than the other RX 7s around town. It has KYB shocks and god knows what else. I can dig trhough the receipts if nothing else.
sold the FD...kept the FB
Joined: Mar 2001
Posts: 1,328
Likes: 1
From: Torrance, CA
Rotary Freak
Joined: Oct 2002
Posts: 2,410
Likes: 2
How nessesary is using the racing beat front lowereing kit (the kit that welds to the top of the strut towers) when using coil overs. I want a good drop but really don't want to cut out my strut towers. Will the shocks bottom out without using this?
