Few questions E85
#26
4th string e-armchair QB
iTrader: (11)
Join Date: May 2005
Location: North Bay, Ontario
Posts: 2,745
Likes: 0
Received 0 Likes
on
0 Posts
I don't know what you're shooting for, but my calcs for fuel went something like this, based on 100 lbs/min of air from a 75mm turbo. You probably will need more airflow by the sounds of it, with your "small" turbo lol.
E85 has a blended stoich of around 9.85:1, I'm sizing for a max rich lambda of .68:1 (10:1 in gas terms). So needs to support 6.7:1 AFR @ 100 lbs/min air, or 14.93 lbs/min of fuel (6.77 kg/min) Estimate of .78 kg/liter density for E85 gives you 8.68 L/min, or roughly 8680 cc/min of fuel. ID2000's max out linearly at like 88-90% at 13V, and about 2200cc/min of gasoline (would be a little more actually for alcohols due to difference in density) So 4 could hypothetically do it, 6 would be better, depending on your power goals. You might even be able to down-size the primaries for better idle if you wanted to.
There's nothing wrong with having too much injector to some extent. In my case I'm using 8x cheap Bosch 1600's, which although they suck on the high and low end of DC, are almost as linear as ID's in the middle, so over-sizing is better in my case to stay out of the <20% and >80% DC's where things get a little wonky.
E85 has a blended stoich of around 9.85:1, I'm sizing for a max rich lambda of .68:1 (10:1 in gas terms). So needs to support 6.7:1 AFR @ 100 lbs/min air, or 14.93 lbs/min of fuel (6.77 kg/min) Estimate of .78 kg/liter density for E85 gives you 8.68 L/min, or roughly 8680 cc/min of fuel. ID2000's max out linearly at like 88-90% at 13V, and about 2200cc/min of gasoline (would be a little more actually for alcohols due to difference in density) So 4 could hypothetically do it, 6 would be better, depending on your power goals. You might even be able to down-size the primaries for better idle if you wanted to.
There's nothing wrong with having too much injector to some extent. In my case I'm using 8x cheap Bosch 1600's, which although they suck on the high and low end of DC, are almost as linear as ID's in the middle, so over-sizing is better in my case to stay out of the <20% and >80% DC's where things get a little wonky.
#27
Thanks for the input on fuel and e85. I have not bought a pump nor injectors yet still gathering information.
#28
Rotary Enthusiast
Join Date: Aug 2006
Location: Melbourne FL/San Antonio TX/Okinawa Japan
Posts: 1,216
Likes: 0
Received 10 Likes
on
10 Posts
By no means am I saying this turbo will not work. IT will and will work great.
use to run 1600 bosch primaries and they worked great. Idle and maxed out at 6psi at 8000rpms. Any smaller IMO would make it a bit harder to tune the transition. Cause now you have to go even bigger secondaries. Just upgraded my primaries to seimen deka 220lbs. Idle and start seems good so far. Looks like they will go to 9 psi and hoping that will allow my secondary injectors to come on at a higher PW. More in the linearly PW of the 1600 bosch injectors.
use to run 1600 bosch primaries and they worked great. Idle and maxed out at 6psi at 8000rpms. Any smaller IMO would make it a bit harder to tune the transition. Cause now you have to go even bigger secondaries. Just upgraded my primaries to seimen deka 220lbs. Idle and start seems good so far. Looks like they will go to 9 psi and hoping that will allow my secondary injectors to come on at a higher PW. More in the linearly PW of the 1600 bosch injectors.
#30
4th string e-armchair QB
iTrader: (11)
Join Date: May 2005
Location: North Bay, Ontario
Posts: 2,745
Likes: 0
Received 0 Likes
on
0 Posts
Sk8, I saw you changed turbos, I just meant my calcs were for the S475 I'm gonna run. Sleeper7, that's a good point about primaries. I am currently using the ID1000's for primaries, and I've been worried about staging when I get it running with the 8x 1600 secondaries, I figured with the 1000's I had enough fuel to get into positive boost, but just. Maybe going with ID2000's for primaries to ease transition would be more ideal? I have an LT10s, which is bad enough for transition with 4 standardish sized injectors...
As for fuel pumps, 2x 044's will support ~480 LPH @ 43.5 base and 30 psi boost, which is only good enough for 8000 cc/min (and this doesn't even factor losses from lines, etc) http://www.jayracing.com/images/prod...osch%20044.jpg I have 3x 044's for mine, but I'm thinking about selling them off and going with a mechanical or larger single electric. But I'm lightyears away from running my heap again, lol.
As for fuel pumps, 2x 044's will support ~480 LPH @ 43.5 base and 30 psi boost, which is only good enough for 8000 cc/min (and this doesn't even factor losses from lines, etc) http://www.jayracing.com/images/prod...osch%20044.jpg I have 3x 044's for mine, but I'm thinking about selling them off and going with a mechanical or larger single electric. But I'm lightyears away from running my heap again, lol.
#31
Full Member
iTrader: (4)
I sold my s475. I am going to running a s482 fmw. Chuck has been busting my ***** because I didnt go T6 with 96/88 wheel instead. I was told the new 87mm J-type wheel with 1.25 exhaust flows within 7% of the T6 96mm wheel but since its a T4, billet and w/ race cover it should spool quicker and can move more air. Well just have to see if it chokes out or not like Chuck is saying..
Thanks for the input on fuel and e85. I have not bought a pump nor injectors yet still gathering information.
Thanks for the input on fuel and e85. I have not bought a pump nor injectors yet still gathering information.
#38
Senior Member
iTrader: (3)
Join Date: Apr 2010
Location: Duluth
Posts: 274
Likes: 0
Received 0 Likes
on
0 Posts
Making the switch to E85 and hoping someone could share what kind of 2 cycle they use. I normally use AMSOIL Dominator for premix but a tech from amsoil said that the E85 would not mix the same as 91 Oct and we make have issues with separation. Any thought?
#41
Rotary Enthusiast
Join Date: Aug 2006
Location: Melbourne FL/San Antonio TX/Okinawa Japan
Posts: 1,216
Likes: 0
Received 10 Likes
on
10 Posts
Just ordered Fuelab for this weekends race in Ennis.
