Transmission talk Tex racing t101
09-23-12, 10:18 AM
#26
Senior Member
Thread Starter
iTrader: (2)
Join Date: Mar 2006
Location: gloucester
Posts: 665
Likes: 0
Received 0 Likes
on
0 Posts
$2650 for the trans
clutch another $160
Hurst shifter $40
Driftshaft reweld/balance $100
So in reality i should be right around my budget of $3k
09-25-12, 04:48 PM
#28
Senior Member
Thread Starter
iTrader: (2)
Join Date: Mar 2006
Location: gloucester
Posts: 665
Likes: 0
Received 0 Likes
on
0 Posts
jeremy lowe has the same trans as i do and he had to cut and modify his tunnel shifter area. The "long" shifter sits off to the side of the trans and it has to be modded. A small price to pay for awesomeness
09-27-12, 04:25 PM
#29
LOPEY IDLE
so basicly you just have widen the hole for the shifter to the left?
09-29-12, 02:28 PM
#32
Senior Member
Thread Starter
iTrader: (2)
Join Date: Mar 2006
Location: gloucester
Posts: 665
Likes: 0
Received 0 Likes
on
0 Posts
not yet. still waiting on my adapter to be machined. I meant that the tunnel area where the shifter goes needs to be widen. In realiality is all very simple. T2 bell housing, starter, adapter, 26 spline disc, trans mount and a drifveshaft.
09-29-12, 02:32 PM
#33
LOPEY IDLE
well were do you get those last 4 things? and can u post some good pics of the install when you do it?
10-02-12, 12:32 PM
#34
Senior Member
Thread Starter
iTrader: (2)
Join Date: Mar 2006
Location: gloucester
Posts: 665
Likes: 0
Received 0 Likes
on
0 Posts
I will. The adapter im making it. ACT has a 26 sline disc, trans mount im making, and the drive shaft. Its not a plug and play swap, but it not hard to do
08-01-13, 06:27 PM
#41
Senior Member
Thread Starter
iTrader: (2)
Join Date: Mar 2006
Location: gloucester
Posts: 665
Likes: 0
Received 0 Likes
on
0 Posts
Sorry guys for not updates, but the trans is in and the car moves under it. Just got to get it tuned and we are in business. I drove it up and down the street and the straight cut gears sound like the "******* devil" singing. 13b street ported with a big turbo and a sequention box sound intense. Can wait to show you guys in car videos of me drifting with it.
Parts updates:
1. I got a Gforce bellhousing adapter for a TII to GM $400 and i also had my input shaft machined by them
2. Went with a clutch master 26 spline disc and their pressure plate $500
3. Driveshaftshop aluminum shaft with billet yoke $450
Im not at home right now for part numbers but if anyone needs this info i can supply it. Every part is available for purchase online and a every easy swap if you are able to make your own mounts for the trans and diff.
Parts updates:
1. I got a Gforce bellhousing adapter for a TII to GM $400 and i also had my input shaft machined by them
2. Went with a clutch master 26 spline disc and their pressure plate $500
3. Driveshaftshop aluminum shaft with billet yoke $450
Im not at home right now for part numbers but if anyone needs this info i can supply it. Every part is available for purchase online and a every easy swap if you are able to make your own mounts for the trans and diff.
08-19-13, 11:27 PM
#42
Well, recently a buddy of mine got me hyped up on these aftermarket transmissions. I may not end up being the first to do this for a drift car but i think that a good alternative to a pricey G-Force or Tex Racing trans would be a Muncie. The M21/M22 have decent enough ratios it looks like, but maybe for drifting a M20 type ratio might make more sense.
In any case, it looks like they can easily handle anywhere from 300-500 ft/lbs, just depends on the amount of grip you have, condition of the transmission and what not.
I may go this route though since you can pick one up from about $600-900 in good condition. Would probably make sense to go with a 26/32 spline set up to make it easier to upgrade to a 'real' racing transmission down the line. But for Pro-Am stuff, I think it's the way to go. Lose some weight and hopefully never worry about breaking another FC 5-Speed.
(I'll just leave this right here)
Muncie 4 Speed Transmissions and Parts
Bellhousing - Mazda RX-7 13B/20B to Muncie/Jerico Transmissions
(^ the adapter is a bit pricey but a good alternative if you can't find a G-Force Adapter Plate)
In any case, it looks like they can easily handle anywhere from 300-500 ft/lbs, just depends on the amount of grip you have, condition of the transmission and what not.
I may go this route though since you can pick one up from about $600-900 in good condition. Would probably make sense to go with a 26/32 spline set up to make it easier to upgrade to a 'real' racing transmission down the line. But for Pro-Am stuff, I think it's the way to go. Lose some weight and hopefully never worry about breaking another FC 5-Speed.
(I'll just leave this right here)
Muncie 4 Speed Transmissions and Parts
Bellhousing - Mazda RX-7 13B/20B to Muncie/Jerico Transmissions
(^ the adapter is a bit pricey but a good alternative if you can't find a G-Force Adapter Plate)
Last edited by ruddyrid; 08-19-13 at 11:31 PM. Reason: Spell Check
06-02-14, 02:10 AM
#46
Junior Member
Join Date: Oct 2013
Location: richmond, va
Posts: 10
Likes: 0
Received 0 Likes
on
0 Posts
Do you have the part number for the clutch you used? I can only find 5.5 and 7.25 multi discs that will work. If you have a single disc i'm interested please. How do you like your T-101?
